Analytik Jena SPECORD 200 User Manual

Peltier temperature-controlled cell holders/cell changers
Peltier temperature-controlled cell holder, air-cooled
1
2
3
4
1 Base plate 3 Draining screw with gasket
2 Guide rail stop 4 Cell block with insulation
Fig. 13-5 Bottom of Peltier temperature-controlled 1x cell holder
The part of the cell sensor immersing in the cell is made of Teflon and thus largely
chemically resistant. The upper part of the sensor consists of an anodized aluminum cap
with an opening for the gold-plated conductive tracks. These materials, too, are as far as
possible corrosion-resistant.
Caution! Ingress of solvents in the sensor!
Avoid immersing the sensor completely in solvents, as they might enter the interior of the
sensor.
User’s Manual SPECORD 200/205/210/250 – Accessories 07/2005 61
Analytik Jena AG
