Analytik Jena SPECORD 200 User Manual

Peltier temperature-controlled cell holders/cell changers
Peltier temperature-controlled 6-cell changer
13.3.3 Technical data of Peltier temperature-controlled 6-cell changer
Operating principle Thermoelectric heating and cooling
Cooling of rear panel of TEC Water-cooled
Guaranteed regulated
temperature range at 25°C
ambient temperature
PTC 600 with heat exchanger WC 600:
+10°C...+60°C
PTC 601 with heat exchanger WC 601:
-5°C...+105°C
Block temperature setting range PTC 600 with heat exchanger WC 600:
+5°C - +65°C
PTC 601 with heat exchanger WC 601:
-20°C...+105°C
Setting accuracy 0.1 degree
Reading accuracy 0.1 degree
Regulating accuracy +/– 0.1 degree
Overview 13-6 Technical data of PTC 600 / PTC 601
Technical data of control unit
Weight 2.5 kg
Dimensions (W x H x T) 225 x 130 x 200 mm
3
Line voltage 100 - 240 V
Line frequency 50 ... 60 Hz
Power consumption 150 VA
Line fuses 2 x T 2.5 A/H 250V, Type 19181
(Wickmann)
EMC (jamming and noise immunity) as per
DIN EN 61326 and 61326/A1
The device can be installed and
operated in all environments.
Fire resistance of the case of the control unit
according to UL94
HB / 1,6
Protection Type IP 20
Data interface RS232 port
Operating temperature range +15°C...+35°C
Transport and storage temperature range -40°C ... +60°C
Relative humidity up to 90% (at +30°C)
Overview 13-7 Technical data of control device for PTC 600 / PTC 601
User’s Manual SPECORD 200/205/210/250 – Accessories 07/2005 71
Analytik Jena AG
