18
ION-B User Manual
The Remote Unit (TFAx) is a device which provides optical-to-electrical downlink conversion
and electrical-o-optical uplink conversion, thus allowing a bidirectional transmission of
signals between the Master Unit and the remote antennas. It is available in 3 different power
confi gurations (Low/Medium/High), housed by 4 different architectures (Case B, Case R, Case
R2 and Case F), so as to fulfi l different coverage and band requirements.
In downlink, each TFAx receives an optical signal from the Master Unit, performs an optical-to-
RF conversion, and transmits the resulting signal to the 2 antenna ports.
In uplink, it receives an RF signal from the remote antennas, provides an RF-to-optical
conversion, and conveys the converted signal to the Master Unit through optical fi bres.
The ION_B Remote Units are available both with power supply 90÷264 Vac and with power
supply -72÷-36 Vdc. Each ION-B Remote Unit is provided with a suitable external power
adapter (TPSNx: please refer to table 2.1).
Last, each ION-B Remote Unit has a wideband auxiliary channel, which can be exploited for
dedicated RF distribution.
Remote UnitS and accessories
Unit name/
Module name
Description Dimensions (L x W x H)
TFAx-case A
TFAx Case B
TFAx Case R
TFAx Case R2
TFAx Case F
TFBWx
TKA04
TPSN 1-40
TPSN 1-80
TPSN 3-30
TPSN 3-80
Remote Unit
Remote Unit
Remote Unit
Remote Unit
Remote Unit
WLAN booster
Remote Unit installation kit
External power supply
External power supply
External power supply
External power supply
200 x 240 x 38 (mm)
240 x 240 x 38 (mm)
330 x 200 x 122.5 (mm)
330 x 250 x 122.5 (mm)
546 x 253 x 207 (mm)
240 x 200 x 38 (mm)
340 x 240 x 55 (mm)
175 x 80 x 54 (mm)
175 x 80 x 51 (mm)
Table 2.1: Different cases of ION-B Remote Units,
with dedicated ION-B accessories.
