72
ION-B User Manual
TFAM
Case R
the Remote Unit. The suggested installation position is side by side to the power supply or
to the Remote Unit, using one of their M6 anchors already installed to support the splice
box as well (please see Fig. 3.4.5g, 3.4.5h).
NOTE: Take care not to bend the fi bers too much.
5 - Now connect the RF cables, the optical connectors, and the power supply connector to
the Remote Unit (Fig. 3.4.5i ). Take care to connect UL and DL fi bers properly.
After the Remote Unit has been properly cabled, insert the power plug in the external
power supply adapter, so as to connect it to the mains.
6 - A fi ber protection can be placed around DL optical fi bers (Fig. 3.4.5l ).
TFAx Case R Troubleshooting
Please refer to the TFAx Case R and Case R2 troubleshooting for a full overview of the
troubleshooting procedures for Case R Remote Units.
