3.7. Case F Remote Unit
Dimensions and Weight
Dimensions: mm. 564 x 255 x 167
(inches 21.5 x 10 x 8.1)
Weight: please refer to the Remote Unit dedicated bulletin in order to know the updated
data about the weight of your case-F Remote Unit.
Figure 3.6.1: Case F Remote Unit (a)
with connector panel (b)
(a)
(b)
Power supply
connector
UL optical
port
DL optical
port
RF auxiliary
DL channel
LED alerts
Green =power ON;
Red = major alarm
RF antenna
port
RF auxiliary
UL channel
