CNC Motion Setup/Testing Utility
P/N 70000635C
All rights reserved. Subject to change without notice.
November 2009
33
BackUp Amp
ble, P/N
ile
,
Reset Amplifier
This feature is only for systems equipped with an ANILAM AC Amplifier
(P/N 33001279) and with the Servo Amplifier Communications Cable, P/N
33001389, connected.
This resets the AC amplifier.
Settings
This feature is only for systems equipped with an ANILAM AC Amplifier
(P/N 33001279) and with the Servo Amplifier Communications Ca
33001389, connected. Refer to “Restore from Backup.”
To backup amplifier parameters:
1. Select an axis (i.e., X, Y, Z, U).
2. Press Misc (F9) to display the pop-up menu.
3. Highlight BackUp Amp Settings and press
ENTER. A message is
displayed indicating the amplifier backup file is created.
This reads all parameters from the amplifier and creates a backup f
named DIGAMP-*.BK, where ‘*’ is the selected axis name (i.e., X, Y, Z
U). This file is stored on the hard disk drive.
NOTE: The backup file is compatible with the file generated by
MotionMaestro. When functions pertaining to ANILAM AC Drive
are selected, the user needs to have a RS-232 communication
cable connected between the amplifier and the CNC.
Restore from BackUp
ature is only for systems equipped with an ANILAM AC Amplifier
eters from backup:
Restore from BackUp
ed i
a
This sends the parameters in the backup file to the amplifier.
This fe
(P/N 33001279) and with the Servo Amplifier Communications Cable, P/N
33001389, connected.
To restore amplifier param
1. Select an axis (i.e., X, Y, Z, U).
2. Press Misc (F9) to display the pop-up menu.
3. Highlight and press
ENTER. A message is
display ndicating the amplifier backup file is restored created.
4. Press Misc (F9) to display the pop-up menu, highlight Reset
Amplifier nd press
ENTER.
