Anilam 3000M - Page 43

CNC Motion Setup/Testing Utility
P/N 70000635B - Index
All rights reserved. Subject to change without notice Index-1
November 2009
(CTRL + F7), AC systems, 32
3000M CNC Programming and
Operations Manual,
referenced, 1, 7
3000M CNC Setup Utility
Manual, P/N 70000499,
referenced, 4, 37
A
AC systems
amplifier
faults, 28
LED indicators, 28
miscellaneous tests
amplifier test link, 32
parameter files, 23
backup amp settings
procedure, 23
select, 27
balance, test screen, illustration, 26
balancing, servo amplifier outputs, 24
differential DSP
2
board, illustration, 9
digital amplifier
balance adjustment (mV), setting, 24
enable, active, 24
illustration, 24
settings, to set, 24
signal gain adjustment (%), setting, 24
DSP
2
board
balance pots, illustration, 23
balancing, 22
earliest, single-ended DSP
2
board, 9
F9, miscellaneous tests, description, 28
invert DAC output, to se, 24
jumpers, description, 21
miscellaneous tests
backup amp settings, 33
CanBus Test, 29
reset amplifier, 33
restore from backup, 33
save amp settings, 32
restore from backup, procedure, 23
servo amplifier, test board, illustration, 20
signal gain (F7), to set, 27
signal gain, test screen, illustration, 27
test board, installation, 21
test points, listed, 21
accessing, MST, 1
activating
MDI, 7
MST screen, 2
active digital amplifier, to set, AC
systems, 24
active status codes area,
illustration, 2
amp parameters
backup amp settings, description, AC
systems, 33
restore from backup, description, AC
systems, 33
amplifier. See Also, servo
amplifier
brushless digital, description, 20
communications cable, 20
communications cable, AC systems, 23
failure, DC systems, 18
faults, AC systems, 28
faults, DC systems, 14
illustration, AC systems, 24
LED indicators, table, AC systems, 28
miscellaneous tests
amplifier test link, AC systems, 32
backup amp settings, AC systems, 33
listed, AC systems, 28
reset amplifier, AC systems, 33
restore from backup, AC systems, 33
save amp settings, AC systems, 32
outputs, balancing, AC systems, 24
parameter files, AC systems, 23
servo fault, resetting, DC systems, 17
servo outputs, balancing, AC systems, 24
settings, AC systems, 23
settings, backup, AC systems, 33
test board
description, AC systems, 20
illustration, AC systems, 20
test points and jumpers, listed, AC
systems, 21
test link, miscellaneous tests, description,
AC systems, 32
analog input offset, AC systems,
32
axis resolution, checking, 5
axis, selecting, 4
B
backup amp settings
description, AC systems, 33
procedure, AC systems, 23
select, AC systems, 27
