1-8 Recommended Test Equipment Chapter 1 — General Information
1-8 PN: 10410-00730 Rev. D MN469xC Series Multiport Test Set MM
1-8 Recommended Test Equipment
Below, Table 1-1 provides a list of recommended test equipment needed for the performance verification and
troubleshooting procedures presented in this manuals.
Table 1-1. Recommended Test Equipment List (1 of 2)
Instrument Critical Specification
Recommended Manufacturer
and Model Use
Calibration Kit Connector Type: K Anritsu Model 3652A MN4694C
Through Cable
Frequency: DC to 40 GHz
Connector Type: K male to K female
Anritsu Model 3670K50-2
(Qty 2)
MN4694C
Verification Kit Connector Type: K Anritsu Model 3668-1 MN4694C
Adapter Type: V female to K female Anritsu Model 34VFKF50 MN4694C
Adapter
Type: K male to K female
Anritsu Model 33KKF50B
(Qty 2)
MN4694C
Air Line Connector Type: K female Anritsu Model SC7760 MN4694C
Offset Termination
Return Loss: 20 dB
Connector Type: K female
Anritsu Model SC4808 or
SC7888
MN4694C
Calibration Kit Connector Type: V Anritsu Model 3654D MN4697C
Extension Cable
Frequency: DC to 70 GHz
Connector Type: V male to V female
Anritsu Model 3670V50A-2
(Qty 2)
MN4697C
Verification Kit Connector Type: V Anritsu Model 3669B-1 MN4697C
Adapter
Type: V male to V female
Anritsu Model 33VVF50C
(Qty 2)
MN4697C
Air Line Connector Type: V female Anritsu Model T2025-2 MN4697C
Offset Termination
Return Loss: 20 dB
Connector Type: V female
Anritsu Model SC5727 MN4697C
Power Meter
Power Range: 70 to +20 dBm
Anritsu Model ML2437A or
ML2438A
All Models
Power Sensor
Frequency: 70 kHz to 70 GHz
Connector Type: V male
Anritsu Model SC7770 All Models
Adapter Type: N male to V female Pasternack Model PE9720 All Models
PC Controller
Configuration:
– 1 gigahertz (GHz) or faster
32-bit (x86) or 64-bit (x64)
processor
– At least 2 GB RAM
– Windows 7 (32-bit or 64-bit)
– 20 MB Hard-disk free space
– 1024x768 Display Resolution
– CD-ROM Drive
– USB 2.0 Type A Port
– National Instruments
GPIB Controller and Driver
– National Instruments
NI-VISA Version
Any All Models
