MN469xC Series Multiport Test Set MM PN: 10410-00730 Rev. D 5-1
Chapter 5 — Component Replacement
5-1 Introduction
This chapter provides procedures for removing and installing replaceable components and sub-assemblies in
the MN469xC Series Multiport Test Set.
5-2 Equipment Required
All procedures require the use of the following tools:
• Either a #1 or #2 size Phillips screwdriver
• 5/16 inch open end wrench
• Anritsu 01-201 (8 lbfꞏin) 5/16 inch torque wrench.
Some procedures require the use of the following tools:
• Small jewelers Phillips screwdriver
• Right angle (offset) #1 size Phillips screwdriver
• Right angle (offset) 5/16 inch open end wrench (for loosening RF connectors inside the front panel)
• Adjustable wrench, 4 inch length, 9/16 inch Jaw Opening
• 36 lbfꞏin Torque Wrench with 1/2” Open End Head Mountz MTBN10 with 1/2” Open End Head or
equivalent.
• 15 lbfꞏin Torque Wrench with 13/16” Socket Craftsman 009-44594 with 13/16” deep socket on 3/8” drive
or equivalent
Caution
Always use a torque wrench calibrated to 8 lbfꞏin when tightening the RF connectors on semi-rigid
RF cables. Over-torquing will cause damage to the RF connectors.
