Anritsu VectorStar MN469 C Series Maintenance Manual

2-3 Replaceable Parts Chapter 2 — Replaceable Parts
2-2 PN: 10410-00730 Rev. D MN469xC Series Multiport Test Set MM
3-64016<R> Low Band Bridge – A20, A21 All Models;
RoHS compliant
ND70079<R> Low Band Switch – A4, A5, A6, A7 All Models;
non-RoHS compliant
3-ND70079<R> Low Band Switch – A4, A5, A6, A7 All Models;
RoHS compliant
70241<R> High Band SPDT Switch Assembly, V Connector, 70 GHz
– A12, A13, A18, A19
MN4697C;
non-RoHS compliant
3-70241<R> High Band SPDT Switch Assembly, V Connector, 70 GHz
– A12, A13, A18, A19
MN4697C;
RoHS compliant
70242<R> High Band SPDT Switch Assembly, K Connector, 40 GHz
– A12, A13, A18, A19
MN4694C;
non-RoHS compliant
3-70242<R> High Band SPDT Switch Assembly, K Connector, 40 GHz
– A12, A13, A18, A19
MN4694C;
RoHS compliant
74278<R> Diplexer Assembly, V Connector, 70 GHz – A8, A10 MN4697C;
non-RoHS compliant
3-74278<R> Diplexer Assembly, V Connector, 70 GHz – A8, A10 MN4697C;
RoHS compliant
74277<R> Diplexer Assembly, K Connector, 40 GHz – A8, A10 MN4694C;
non-RoHS compliant
3-74277<R> Diplexer Assembly, K Connector, 40 GHz – A8, A10 MN4694C;
RoHS compliant
66245<R> Port Coupler, V Connector, 70 GHz – A14, A15 MN4697C;
non-RoHS compliant
3-66245<R> Port Coupler, V Connector, 70 GHz – A14, A15 MN4697C;
RoHS compliant
66480<R> Port Coupler, K Connector, 40 GHz – A14, A15 MN4694C;
non-RoHS compliant
3-66480<R> Port Coupler, K Connector, 40 GHz – A14, A15 MN4694C;
RoHS compliant
34YK50C K Test Port Connector – Mounts on A14, A15 MN4694C
34YV50C V Test Port Connector – Mounts on A14, A15 MN4697C
3-62109-42 RF Cable, V Connector, VNA to Test Set, Front Panel MN4697C
3-67357-38 RF Cable, K Connector, VNA to Test Set, Front Panel MN4694C
62112-80 RF Cable, SMA Connector, VNA Bx to Test Set Bx, Rear Panel All Models;
non-RoHS compliant
3-62112-80 RF Cable, SMA Connector, VNA Bx to Test Set Bx, Rear Panel All Models;
RoHS compliant
62112-81 RF Cable, SMA Connector, VNA Src to Test Set Src, Rear Panel All Models;
non-RoHS compliant
Table 2-1. Replaceable Parts List (2 of 3)
Part Number Part Description – Drawing “A” Number Use
