5-6 Rear GPIB Connector PCB Replacement Chapter 5 — Component Replacement

5-6 PN: 10410-00730 Rev. D MN469xC Series Multiport Test Set MM

1. Jumper # 1 goes from pin 12 of the GPIB connector to pin 13 of the GPIB connector.

2. Jumper # 2 goes from pin 12 of the GPIB connector to pin 1 of the Dip Switch connector

Figure 5-5. Back side of GPIB Connector PCB Assembly

24 13

121

JUMPER # 1

JUMPER # 2
