Microlok II System Startup, Troubleshooting, and Maintenance UNION SWITCH & SIGNAL
SM-6800C Rev. 2.5 September 2000 6-5
• Event sub-classes in the range of 0x40 to 0x7f are Level 2 events. When a unit has been
configured to log Level 2 events, all events with sub-classes 0x00 to 0x7f will be logged.
Level 3 events are all events with sub-classes of 0x80 and higher.
• A unit set to Level 3 will log all events.
Levels 2 and 3 should be used for data that would not normally be included in the event logs
but may be required under special conditions. The Level 2 events would normally contain
more detailed information than Level 1 events and less than Level 3 events. The designations
for the event classes are as follows:
Event
Number
Event Class Class Description
1 System Class System level Errors/Events such as clock sets, event
log cleared, etc.
2 CPU Hardware Class Errors/Events directly related to CPU Hardware
3 Diagnostics Class Error/Event in scheduled or background system
diagnostics
4 Executive Class Invalid Execution of executive software
5 Bitstring Class ID Range or value event in bitstring management
6 Static Application Class Application PROM consistency event
7 Dynamic Application Class Application execution event
8 I/O Manager Class Errors/Events related to generic I/O management
9 Input 16 Class Errors/Events related to the INPUT16 board
10 Output 16 Class Errors/Events related to the OUTPUT16 board
11 Mixed I/O Class Errors/Events related to the IN8.OUT8 board
12 Lamp 16 Class Errors/Events related to the LAMP16 board
13 Coder Output Class Errors/Events related to the CODER board
14 Non-vital Class Errors/Events related to the NV.IN32.OUT32 board
15 Non-vital Bipolar Class Errors/Events related to the NVB.OUT12 board
16 MICROTRAX Track Circuit
Class
Errors/Events related to the MICROTRAX track circuit
board
17 Electrified Track Circuit Class Not generated by Microlok II
18 Shared Ram Class Errors/Events related to the Shared Ram Interface
19 Generic Serial Link Class Generic serial link errors/events common across all
link types
20 GENISYS Serial Master
Class
Serial link errors/events related to the GENISYS
Master protocol
21 GENISYS Serial Slave Class Serial link errors/events related to the GENISYS
Slave protocol
22 MICROLOK Serial Master
Class
Serial link errors/events related to the MICROLOK
Master protocol
23 MICROLOK Serial Slave
Class
Serial link errors/events related to the MICROLOK
Slave protocol
