Installation EIA-232 Devices – Remote Printers and CRTs (TB4)
40 IQ-301 PN 50036:F 10/29/2001
Figure 17 shows typical connections for daisy chaining multiple CRTs, printers, or
both. (Refer to CRT configuration in Appendix I.)
Figure 17 Connections For Multiple CRTs or Combined CRTs and Printers
afp2rCRT.cdr
Twisted Pair
To AUX Port of CRT To EIA Port of CRT
with keyboard
To EIA Port of next
CRT or PRN
To TB 4 - 2
To TB 4 - 1
To TB 4 - 3
