3.3.2 Install Hard disk
After taking out Cooler, let’s focus on Installing Drives Cage. Slide hard disk into the Drives Cage,
and use screw no. 3 to screw it firmly to the cage.
3.3.3 Install Floppy Drive
Slide in the floppy drive as shown. Use screw no.2 to screw the 3
rd
and 6
th
hole separately.
Front Mark
Heat dissipation side faces up.
Front mark
Front mark
The bottom of Cooler had been
p
rotected
with a plastic cover when shipped.
Please take it off when
y
ou want to
p
ut the
cooler on CPU.
