AOpen XC Cube - Back Panel; Keyboard and Mouse

Back Panel
2. Connect keyboard and mouse.
3. Connect monitor and tighten screws
PS/2 keyboard connector
PS/2 mouse connector
Monitor connector
Line-In Jack (SUR L/R)
Microphone jack(C/B)
Ethernet network
connecto
r (RJ-45)
USB2.0 connector
IEEE1394 connector
Coaxial Out RCA Port
COM1
Printer Port
S/PDIF IN port
Line-out Jack(L/R)
The pictures above are for reference. Please refer to the EIG for detail.
