3.5.4 Install CPU On Socket A
1. Erect CPU socket lever up and gently put CPU onto Socket
2. Press lever back to CPU socket, and then it’s done.
3.5.5 Install CPU On Socket 479
1. Remove plastic membrane from CPU socket and make sure the drop-shaped indicator on socket
screw aims at open direction (the default is open).
Lever
Socket screw
Plastic membrane
Drop-shaped indicator
