2. Connecting floppy cable, hard disk and optical cable on motherboard for later use.
Optical
device cable
Serial ATA
Cables
As Serial ATA hard disk comes with different power connector, please use our bundled
SATA power connector to connect the hard disk.
Power
Connector
Hard disk
cable
3. If you happen to have Serial ATA hard disk, Except EZ661L, this motherboard comes with Serial
ATA connectors onboard as well. With EzColor design, you may easily find out the correct
flame-red cable with the correct header. You may kindly install the Serial ATA cables onto Serial
ATA headers.
