77
Operation and Questionable Status Registers
7.6.3 Status Subsystem
Command Format
STATus:OPERation[:EVENt]?
STATus:CONDition?
STATus:OPERation:ENABle <numeric_value>
Description Operation Status Registers Enable and Query
Example STATus:CONDition?
Command Format
STATus:OPERation[:EVENt]?
STATus:CONDition?
STATus:OPERation:ENABle <numeric_value>
Description Operation Status Registers Enable and Query
Example STATus:CONDition?
Item Name Value
STAT:OPER:COND? Operation Status Register Query BIT 0 ,01H, (1) Reserved
BIT 1 ,02H, (2) Calibration Mode
BIT 2 to 15 Reserved
STAT:QUES:COND?
Questionable Status Register
Query
BIT 0 ,01H,(1) Reserved
BIT 1 ,02H,(2) Protection Event
BIT 2, 04H,(4) Fatal Error
BIT 3, 08H,(8) Calibration Error
BIT 4, 10H,(16) Interlock Open
BIT 5 – 15 Reserved
