11. Replacement Parts List
Part Number Quantity Ref Designator Description
Supplied Accessories
3318 9 1 - 8505 Input Power Cable
39534 1 - Romex cable strain relief 1"
40291 2 - Romex cable strain relief 1/2"
40257 1 - Interlock Key
40280 2 - 2U Rack Mount Handle
40281 2 - 2U Rack Mount Bracket
40290 1 - Protective Junction Box for Output Terminals (2U)
40338 1 - Protective Junction Box for Output Terminals (8540)
40321 1 - Protective Junction Box for Input Terminals
40328 1 - Shorting Bar (4U)
40298 3 - Shorting Bar (2U)
39066 1 - USB Cable AB Type 1.8m
Panel Components
40253 1 - Display LCD 480 X 272
40265 1 - Grey Dust Cover
38102 2 - Rubber inserts for front legs
40001 1 - Four piece plastic legs kit
40000 2 - Rubber inserts for back legs
40319 1 - Three-pole input terminal block
40296 1 - Five-pole output terminal block
38339 2 - Wire form fan guard
39629 1 - Power button key top
40284 1 - Top Cover
40285 1 - Bottom Chassis (2U)
40334 1 - Bottom Chassis (8540)
40286 1 - Front Panel Mounting Bracket (2U)
40335 1 - Front Panel Mounting Bracket (8540)
40339 1 - 8540 Front Panel Fan Cover
40283 1 - Rear Panel (8505)
40320 1 - Rear Panel (8512)
40322 1 - Rear Panel (8520)
40336 1 - Rear Panel (8540)
40292 1 - Cover for GPIB Slot
40289 1 - Tray for PLC board
40293 1 - Main Front Panel
40294 1 - Rotary Knob
40295 1 - LCD Protective Panel
40279 1 - Rubber Keypad
40327 7 - Rubber pegs for 8540 front panel fan cover
