2.7 Packaging
Please enclose the instrument with all options, accessories and test leads. All returns must be accompanied
by a return material authorization (RMA) number which is provided by our customer support department.
Failure to ship your instrument without an RMA number will result in additional fees for handling and storage.
APT will not be responsible for any repair costs associated with shipping damage as a result of improper
packaging. The customer is responsible for providing adequate shipping insurance coverage while shipping
an instrument in the event of loss or damage while in transit.
Models 8505 8 512 8520 8540
Input
Phase 1Ø2W
Voltage 100 - 240 V ± 10% 200 - 240 V ± 10%
Max. Current 8A 18A 30A 30A
Power Factor (*1) ≥0.93 at Full load ≥0.97 at Full load
Frequency 47 - 63 Hz
AC Output
Power Rating 1Ø2W 500VA 1250VA 2000VA 4000VA
Max.
Current (r.m.s) (*2)
1Ø2W
0 -
155V
5A @ 100V 12.5A @ 100V 20A @ 100V 40A @ 100V
0 - 310V 2.5A @ 200V 6.25A @ 200V 10A @ 200V 20A @ 200V
Inrush Current
(peak) (*3)
1Ø2W
0 -
155V
20A 50A 80A 160A
0 - 310V
10A 25A 40A 80A
Frequency 5.0 - 1200 Hz
Phase 1Ø2W
THD (Total Harmonic Distortion) (*4)
≤0.3% @ 50/60Hz (Full Resistive Load)
≤1.1% @ 5 -1000Hz (Full Resistive Load)
≤1.2% @1001-1200Hz (Full Resistive Load)
Crest Factor ≥3
Line Regulation ±0.1V
Load Regulation (Hardware) (*5) ± (1% of output +0.5V) @ Resistive Load, < 400µS response time
Load Regulation (Software) (*5) ±0.2V, <1S response time
DC Offset ≤±30mV (typical)
3. Specifications and Controls
3.1 Specifications
