APT 8520 - Page 13

© Ikonix USA
9
Models
8505 8 512 8520 8540
DC Output
Power Rating 300W 750W 1200W 2400W
Max. Current (*2)
0 - 210V 3.0A 7.5A 12.0A 24.0A
0 - 420V 1.5A 3.75A 6.0A 12.0A
Ripple & Noise (rms) (*6) Range
L < 700mV < 800mV
H < 700mV < 800mV
Ripple & Noise (p-p) (*6) < 6.0Vp-p < 7.0Vp-p
Settings
Voltage (AC)
Range 0 - 310V, 155/310V Auto Range
Resolution 0.1V
Accuracy ±(0.2% of setting + 3 counts)
±(0.2% of setting
+ 6 counts)
Voltage (DC)
Range 0 - 420V, 210/420V Auto Range
Resolution 0.1V
Accuracy ±(0.2% of setting + 3 counts)
±(0.2% of setting
+ 6 counts)
Frequency
Range DC, 5 - 1200Hz Full Range Adjust
Resolution 0.1Hz at 0.0 - 999.9Hz, 1Hz at 1000 - 1200Hz
Accuracy (*7)
±0.03% of setting (≥15Hz)
±0.3% of setting (<15Hz)
Start Angle
(Programmable Option)
Range 0-359°
Resolution 1°
Accuracy
5Hz-25Hz: ± 2°
25.1Hz-65Hz: ± 4°
65.1Hz-100Hz: ± 8°
100.1Hz-500Hz: ± 32°
500.1Hz-1000Hz: ± 60°
1000Hz-1200Hz: ± 65°
Current Hi Limit (OC
Fold=OFF)
OC Fold Back
(OC Fold = ON)
0 - 155V 0.05 - 5.00A 0.05 - 12.50A 0.05 - 20.00A 0.10 - 40.00A
0 - 310V 0.05 - 2.50A 0.05 - 6.25A 0.05 - 10.00A 0.10 - 20.00A
Resolution 0.01A
Accuracy ± (2.0% of setting + 4 counts)
OC Fold Back Response Time (*8) < 1.4S (30Hz - 1200Hz)
Time
(Programmable Option)
Range
1.0 - 999.9H
1.0 - 999.9M
1.0 - 999.9s
0.2 - 999.9ms
Resolution
0.1h
0.1Min
0.1s
0.1ms
Accuracy
± (0.1% + 0.1 Hour)
± (0.1% + 0.1 Minute)
± (0.1% + 0.1 sec)
± (0.1% + 0.1 ms)
Time Unit Hour, Minute, Second, ms
