APT 8520 - Page 14

© Ikonix USA
10
Models
8505 8512 8520 8540
Measurement
Ramp Up
(Programmable Option)
Range
0.1 - 999.9s, 0 = OFF
Resolution
0.1s
Accuracy
± (0.1% + 1 Cycle) at Output frequency ≤ 10Hz
± (0.1% + 0.1 sec) at Output frequency > 10Hz
Frequency
Range
0.0~1200Hz
Resolution
0.1Hz / 1Hz
Accuracy
±0.1Hz @ 5 - 999.9Hz.
±1Hz @ 1000 - 1200Hz
Voltage (AC)
Range
0 - 310V, 155/310V Auto Range
Resolution
0.1V
Accuracy ±(0.2% of reading + 3 counts) at voltage > 5V
±(0.2% of reading + 6
counts) at voltage > 5V
Voltage (DC)
Range
0 - 420V, 210/420V Auto Range
Resolution
0.1V
Accuracy ±(0.2% of reading + 3 counts) at voltage > 5V
±(0.2% of reading + 6
counts) at voltage > 5V
Current (AC, DC)
(*9)
Range
L 0.050 - 1.200A 0.050 - 5.000A -
H 1.00 - 6.25A 4.00 - 15.62A 4.00 - 25.00A 0.10 - 50.00A
Resolution
L 0.01A -
H 0.01A
Accuracy
L
± (1% of reading + 10 counts)
at CF < 3
-
H ± (0.5% of reading + 8 counts)
± (0.5% of reading
+12 counts)
Power (AC, DC)
(10*)
Range
L 0.0 - 75.0W 0.0 - 300.0W -
H 60 - 625W 240 - 1563W 240 - 2500W 0 - 5000W
Resolution
L 0.1W -
H 1W
Accuracy
L
± (1% of reading
+10 counts)
at PF ≥ 0.35 and
voltage > 5V
± (2% of reading +15 counts) at PF ≥
0.35 and voltage > 5V
-
H
± (1% of reading
+5 counts)
at PF ≥ 0.35 and
voltage > 5V
± (1% of reading
+10 counts)
at PF ≥ 0.35and
voltage > 5V
± (1% of reading
+10 counts)
at PF ≥ 0.35 and
voltage > 5V
± (1% of reading +20
counts) at PF ≥ 0.35 and
voltage > 5V
Power Factor
Range 0.000 - 1.000
Resolution 0.001
Accuracy W/VA, Calculated and displayed to three significant digits
Power Apparent
(VA)
(Programmable Option)
Range
L 0.0 - 75.0VA 0.0 - 300.0VA -
H 60 - 625VA 240 - 1563VA 240 - 2500VA 0 - 5000VA
Resolution
L 0.1VA
H 1VA
Calculated Formula V×A, Calculated value
