IMPORTANT INFORMATION
4 5
Safety information
This product must be installed by a competent person in
accordance with all relevant current Water Supply Regulations.
ALL PRODUCTS REQUIRING AN ELECTRICAL CONNECTI0N
MUST BE INSTALLED BY A QUALIFIED PERSON FOLLOWING
THE LATEST REVISION OF BS 7671 (WIRING REGULATIONS)
AND CERTIFIED TO CURRENT BUILDING REGULATIONS.
This system should be installed so that other taps or appliances
operated elsewhere within the premises do not significantly aect
the flow.
The Q
TM
shower sytems must not be used with a hot water supply
temperature of over 65ºC.
The Quartz
TM
smart valve is supplied factory pre-set at maximum
temperature of 45ºC. The maximum temperature is fully
adjustable to suit site conditions. If adjusted, we recommend the
outlet temperature is set to a MAXIMUM of 46ºC.
THE QUARTZ
TM
SMART VALVE MUST BE INSTALLED IN AN
ACCESSIBLE LOCATION FOR SERVICING AND MAINTENANCE.
The Quartz
TM
smart valve must not be installed in situations where
either the ambient temperature is likely to exceed 40ºC or where
freezing may occur.
The Q
TM
controller must not be installed in situations where the
ambient temperature is likely to fall below 5ºC or rise above 40ºC.
We do not recommend the use of Q
TM
controller in steam therapy
facilities.
This appliance must be earthed.
Cables which are chased into the wall must be protected by a
suitably sized conduit or sheathing to allow for removal in the event
of service and maintenance purposes. Ensure that the conduit is
run to avoid the controller fixing holes.
Surface mounted cables must also be protected by a suitable
approved conduit, even in a loft, where there may be a risk of
damage from vermin.
The power lead must only be replaced by the manufacturer or
his accredited agent.
The Q
TM
controller is supplied from a safety low voltage source.
This product is suitable for domestic use only.
Aqualisa smart products are supplied complete with a 1 year
guarantee that can be upgraded to 5 years by registering the
shower with Aqualisa.
This product is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities or lack of
experience and knowledge, unless they have been given initial
supervision or instruction concerning the use of the product by
a person responsible for their safety.
Children should be supervised to ensure they do not play with the
product.
Installation of pumped Quartz
TM
smart valve (for gravity
stored systems)
The pumped Quartz
TM
smart valve is designed to operate up to
maximum static pressure of 100kPa ((1 bar)(10 metres head)
(14.5psi)).
Under no circumstances must the pumped Quartz
TM
smart valve
be connected directly to the water main or in line with another
booster pump.
The minimum actual capacity of the cold water storage cistern
should be not less than 225 litres (50 gallons). The capacity of the
hot water cylinder must be capable of meeting anticipated demand.
Installation of Quartz
TM
smart valve (for balanced high
pressure and unvented systems, combination boiler
systems and separately pumped gravity systems)
Pressures: The Quartz
TM
smart valve system is designed to operate
up to a maximum static pressure of 700kPa ((7 bar)(100psi)). Where
pressures are likely to exceed 700kPa ((7 bar)(100psi)), a pressure
reducing valve must be fitted to the incoming mains supply.
A setting of 400kPa ((4 bar)(60psi)) is recommended. It should be
noted that daytime pressures approaching 600kPa ((6 bar)(80psi))
can rise above the stated maximum overnight.
