4.2 PARTS SCHEMATICS
10
1. TOP LID 12. ELECTRONIC TX VALVE
2. UPPER COVER 13. 5V SENSORS
3. ELECTRONIC MAIN BOARD 14. DISPLAY COVER
4. ELECTRIC ANODE TRANSFORMER 15. DISPLAY CONTROLLER
5. FAN CAPACITOR 16. FOAM FAN COVER
6. AC TO DC TRANSFORMER 17. FAN BLADE
7. COMPRESSOR RUN CAPACITOR 18. FAN MOTOR
8. COMPRESSOR STARTER 19. THERMAL SENSOR
9. COMPRESSOR WIRING HARNESS 20. ELECTRONIC ANODE
10. COMPRESSOR 21. ELECTRIC HEATER
