SPECIFICATIONS
RAPID/X6 DYNAMIC/X8
DIMENSIONS PACKED
700mm X 700mm X 1730mm 700mm X 700mm X 1950mm
DIMENSIONS UNPACKED
620mm X 1580mm 620mm X 1800mm
WEIGHT: Unpacked/ Packed / Filled
103KG / 118KG / 328KG 118KG / 134KG / 378KG
TANK
STORAGE VOLUME | HEATED VOLUME
225L | 222L 268L | 263L
MATERIAL | THICKNESS: Dome / Wall
CARBON STEEL | 3.0mm / 2.5mm CARBON STEEL | 3.0mm / 2.5mm
ENAMEl: Coating / Rating
BLUE DIAMOND / CLASS X BLUE DIAMOND / CLASS X
ANODE PROTECTION
NON-SACRIFICIAL IMPRESSED CURRENT NON-SACRIFICIAL IMPRESSED CURRENT
INSULATION: Type / Thickness / Heat Loss
POLYURETHANE | 40MM | 2.5KWH (24HRS) POLYURETHANE | 40MM | 2.8KWH (24HRS)
PTR RATING | CONNECTION
850kPa | 1/2”G 850kPa | 1/2”G
INLET CONNECTIONS | TYPE
3/4”G | DUAL HAND 3/4”G | LEFT HAND
HEAT PUMP
REFRIGERANT: Type / Charge / Pressure
R290 / 400G / 3000 R290 / 400G / 3000
COMPRESSOR: Brand / Type
GMCC TOSHIBA / ROTARY GMCC TOSHIBA / ROTARY
VALVES: Expansion / Defrost
ELECTRIC / 4-WAY VALVE ELECTRIC / 4-WAY VALVE
LOW TEMP CLASSIFICATION
CLASS A CLASS A
FAN: Type / Discharge / Flow Rate
CO-AXIAL / HORIZONTAL / 0.153
M³/S CO-AXIAL / HORIZONTAL / 0.153 M³/S
EVAPORATOR: Dimensions / Rows / Material
420X 350 420X 350
HEAT EXCHANGER: TYPE / MATERIAL
MICROCHANNEL / ALUMINUM ALLOY MICROCHANNEL / ALUMINUM ALLOY
OPERATING NOISE LEVEL
42 42
@ 1.65m per (Per Standard ISO 3745:2012) 61 61
MAX TEMP: Heat Pump / Element
60°C / 70°C 60°C / 70°C
AMBIENT RANGE: Heat Pump / Element
-5°C 43°C / -15°C 50°C -5°C 43°C / -15°C 50°C
CONTROLLER: Input / Power / Wi-FI / App
LCD ANALOGUE LCD ANALOGUE
HEATING MODES
ECO STAND HYBRID HYBRID+ ELEMENT ECO STAND HYBRID HYBRID+ ELEMENT
COMPRESSOR:
Draw/ Current / Capacity
900W / 3.75 Amp / 3500W 900W / 3.75 Amp / 3450W
ELEMENT: Rating / Connection / Thermostat
1800W / FLANGE / ROBERT SHAW 1800W / FLANGE / ROBERT SHAW
ELECTRICTY: Supply / Min Circuit Rating
220-240 V/50-60HZ / 10 AMP-SINGLE PHASE 220-240 V/50-60HZ / 10 AMP-SINGLE PHASE
CAPACITY BY OPERATING MODE
STANDARD HYBRID HYBRID+ STANDARD HYBRID HYBRID+
STORED ENERGY 15.62kW 16.52kW 17.43kW 18.49kW 20.52kW 21.58kW
OUTPUT: 45°C HOT OUT @ 10°C COLD IN 315L 340L 360L 375L 405L 430L
OUTPUT: 45°C HOT OUT @ 15°C COLD IN 335L 360L 385L 395L 425L 455L
OUTPUT: 45°C HOT OUT @ 20°C COLD IN 355L 385L 415L 420L 460L 495L
CLIMATE (WARM = ZONES 1/2/3 | COOL = 4/5)
TARIFF (24HR = CONTINUOUS / 8HR = CONTROLLED OR SOLAR TIMERS)
SIZING RECOMMENDATIONS
W / 24hr W / 8hr C / 24hr C / 8hr W / 24hr W / 8hr C / 24hr C / 8hr
# OF OCCUPANTS 6 4 4 3 8 5 6 4
# OF BEDROOMS 4 3
3 3
4 4 4 3
# OF BATHROOMS 2 2
2 1
3 2 2 2
COP | CAPACITY | LPH | RECOVERY TIME
@ 0°C WET BULB TEMPERATURE 2.50 1500W 30L 7hr 25min 2.50 1500W 30L 8hr 40min
@ 7.5°C WET BULB TEMPERATURE 3.45 2180W 46L 4hr 45min 3.50 2125W 45L 5hr 55min
@ 15°C WET BULB TEMPERATURE 4.68 3165W 67L 3hr 18min 4.38 2950W 62L 4hr 15min
@ 20°C WET BULB TEMPERATURE 5.00 3500W 75L 2hr 55min 5.09 3450W 73L 3hr 35min
CLIMATE ZONE
STC VALUES
1
2 3 4 5 1 2 3 4 5
ASSIGNED STC VALUE 25 23 30 32 31 25 24 31 33 31
2024 DEEMED STC VALUE 18 16 21 22 21 18 17 21 23 23
2025 DEEMED STC VALUE 15 13 18 19 18 15 15 18 19 19
