ARB 3940420 - Page 3

Last Rev Date 17/05/2019
Page 3 of 36
Fitting instructions# 3789528
Copyright © 2005 by ARB Corporation Limited. All rights reserved, this document must not be reproduced without the express authority of ARB Corporation Ltd
APPLICATION.
PART NO.
DESCRIPTION
QTY
FIT MOUNT
BRACKET TO
CHASSIS
3759563
BRACKET CHASSIS MOUNT RANGER LRG RAD
1
3759574R
BRACKET CHASSIS BRACE INNER RIGHT
1
3759574L
BRACKET CHASSIS BRACE INNER LEFT
1
3759575R
BRACKET CHASSIS BRACE OUTER RIGHT
1
3759575L
BRACKET CHASSIS BRACE OUTER LEFT
1
3759576R
BRACKET BULL BAR BRACE RIGHT
1
3759576L
BRACKET BULL BAR BRACE LEFT
1
4584375
SPACER Ø1 ¼” 15MM THICK
2
5848427
PACKER CHASSIS 5MM THICK
4
6151357
BOLT SEMS M10 X 30 ZP Gd 8.8
10
4581011
WASHER FLAT, M12 x 27 x 4
10
4581083
WASHER FLAT, M10 x 21 x 2 ZP
2
4581050
WASHER SPRING 1/2 x 3/16 x 3/16 ZP
10
4581048
WASHER SPRING M10 TZP480
2
6151360
BOLT M12 x 1.75 x 35 Gd 8.8 ZP
10
6151428
NUT FLANGE M12 X 1.75 ZP
10
6151456
BOLT M10 x 1.5 x 45 Gd 8.8 ZP
2
6151727
BOLT HXFL M16 x 2.0 x 35 FT PC8.8 TZP
2
6151728
NUT FL SM M16 x 2.0 PC8 TZP
2
FIT BAR TO
MOUNT
BRACKET
4584376
SPACER Ø1 ¼ “ 35MM THICK
2
6151357
BOLT SEMS M10 X 30 ZP Gd 8.8
4
6151306
NUT CAGED M12 1.8-3.2
6
4581050
WASHER SPRING 1/2 x 3/16 x 3/16 ZP
6
6151360
BOLT M12 x 1.75 x 35 Gd 8.8 ZP
4
6151168
BOLT M12 x 1.75 x 80 CL8.8 ZP
2
3194293
PLATE NUT MOUNT RANGER T6
2
4581007
WASHER FLAT 1/2 x 1.1/2 x 4MM SILVER
6
6151321
NUT FLANGE M10 x 1.5 ZP
12
MISC
3789424
CUTTING TEMPLATE BUMPER RANGER 15 ON
1
6151349
8 - 15 X 15mm BUTTON HEAD SELF TAPPING GP
4
180302
CABLE TIE 4.8 X 180 MM BLACK
12
6191037
PINCH WELD 1000mm
1
FIT LICENSE
PLATE
BRACKET
6151213
BOLT M6 x 1.0 x 20 Gd8.8 BZ
3
4581287
WASHER SPRING M6 x 2.5 x 1.6 BLK ZN
3
4584295
WASHER FLAT M6 X 12 X 1.3 BLK ZN
3
6151128
NUT FLANGE M6 x 1.0 ZP
3
3759488
BRACKET LIC PLATE FIXED LARGE RAD
1
6821189
GROMMET RND FC 1500 080 090
2
6151384
SCREW 10G x 5/8 SELF TAPPING
2
FIT WINCH
ACCESS PANEL
6151213
BOLT M6 x 1.0 x 20 Gd8.8 BZ
4
4581287
WASHER SPRING M6 x 2.5 x 1.6 BLK ZN
4
4584295
WASHER FLAT M6 X 12 X 1.3 BLK ZN
4
6151128
NUT FLANGE M6 x 1.0 ZP
4
6522985
PRESS FORM WINCH COVER PANEL
1
