148. Fit the Sensor Housing Front to the bull bar.
Placing the housing through the bar from the
front of the vehicle.
IMPORTANT:
Check orientation of sensor housing.
Front Sensor housing must be parallel to
ground (as shown below).
149. From the rear of the bar clip the Sensor
housing rear to the front housing. Check that
both clips are engaged properly. If clips don’t
engage apply pressure on the outer ring of
the rear housing.
150. Replace the manufacturer’s clear rubber
grommets with the new rubber grommets
supplied.
151. Clip the sensor into the housing. Check that
both clips are engaged properly.
NOTE: Loom connectors should all be pointing
toward the centre of the car.
IMPORTANT:
152. Ensuring the clear silicone grommet
remains on sensor.
153. Ensure sensor is central in hole and not
pressed to one side.
154. Ensure sensor installed in the correct
orientation.
155. Reattach parking sensor to loom.
