Fitting instructions# 3789528
Copyright © 2005 by ARB Corporation Limited. All rights reserved, this document must not be reproduced without the express authority of ARB Corporation Ltd
Note: Read the instructions thoroughly before
starting.
1. Open the bonnet and remove the screws and
retaining clips used to retain the plastic cover
above the grille.
Carefully detach plastic cover.
Note: Everest requires the 2 bolt securing air
duct to be removed.
FOR RANGER:
2. Remove the screws and retaining clips used
to retain grille.
Carefully detach grille piece from vehicle.
FOR EVEREST:
3. Remove 2 screws retaining grille.
Retain screws and clips.
Note: Take note where fasteners are removed
from as some have to be replaced later in the
fitment.
4. Remove all the bumper fasteners along the
inside edge of the wheel arches.
FOR RANGER:
5. Remove all the fasteners securing the bottom
of the bumper to the vehicle.
