Fitting instructions# 3789528
Copyright © 2005 by ARB Corporation Limited. All rights reserved, this document must not be reproduced without the express authority of ARB Corporation Ltd
FITTING PROCEDURE – SAHARA BUMPER
Note: If installing in Sahara Bumper configuration proceed from here using Buffer Kit
5100230 Then continue from Step 145. If installing in Sahara Bar configuration (with
top tube installed) please skip to step 142.
141. From the rear of the bar, slide the rear buffer sections into the front sections as shown. Ensure the
tongue section on both sides of each buffer engages into the slots of the front sections. Fit 4 x screws
and washers. Tighten screws once correct fitment is achieved.
Fit washers under screw heads.
Generic image. Bull
Bar shown may not
be representative
of actual product.
