ARB 3940420 - Parts Listing

Last Rev Date 17/05/2019
Page 4 of 36
Fitting instructions# 3789528
Copyright © 2005 by ARB Corporation Limited. All rights reserved, this document must not be reproduced without the express authority of ARB Corporation Ltd
PARTS LISTING
APPLICATION.
PART NO.
DESCRIPTION
QTY
FIT UNDER
PANELS
6522940R
PANEL UNDER WING RANGER 11ON
LRG RAD
1
6522940L
PANEL UNDER WING RANGER 11ON
LRG RAD
1
3758957
BRACKET WING PANEL RANGER T6
2
6151132
NUT FLANGE M8 x 1.25 ZP
7
4581082
WASHER FLAT, M6 x 19 x 1.6 BZ
10
4581047
WASHER SPRING M8 x 3/32 x 3/33 BLK
14
4581287
WASHER SPRING M6 x 2.5 x 1.6 BLK ZN
10
6151234
BOLT M8 x 1.25 x 25 Gd 8.8 BP
14
6151213
BOLT M6 x 1.0 x 20 Gd8.8 BZ
10
6151300
NUT CAGED M6 2.6-3.5
10
6151301
NUT CAGED M8 3.3-4.7
7
6522838
PANEL SPLASH RANGER T6
1
3758956
BRACKET OE STONE SHEILD RANGER T6
1
6151357
BOLT SEMS M10 X 30 ZP Gd 8.8
2
6151321
NUT FLANGE M10 x 1.5 ZP
2
4581307
WASHER FLAT, M8 x 20 x 2 BLK ZN
14
LIGHTS AND
MOULDINGS
6821287
LAMP LED INDICATOR CLEARANCE
1
3163082
KIT SURROUND ARB FOGLIGHT
1
6821116
GROMMET NYLON SNAP IN TYPE
4
3500880
GRILLE SPLIT PAN KIT
1
5100200
BUFF KIT 2PCE FRONT SECTION
1
5100210
BUFF KIT 2PCE REAR UPRIGHT BAR
1
DIGITAL RADIO
ANTENNA
RELOCATION
6151464
SCREW BUTTON HEAD M8 x 1.25 x 25 BLK ZN
2
4581047
SPRING WASHER M8 BLK ZN
2
4581307
WASHER FLAT M8 BLK ZN
2
6151548
NUT FLANGE M8 x 1.25
2
PARKING
SENSORS
3500960
SENSOR SURROUND KIT
1
3163222
BLANKING PLUGS
2
WING BRACE
4681588R
BRACE WING RH
1
4681588L
BRACE WING LH
1
6151045
BOLT M10 x 1.5 x 25
8
4581083
WASHER FLAT, M10 x 21 x 2 ZP
8
4581048
WASHER SPRING M10 TZP480
8
6151321
NUT FLANGE M10 x 1.5 ZP
8
