Fitting instructions# 3789528
Copyright © 2005 by ARB Corporation Limited. All rights reserved, this document must not be reproduced without the express authority of ARB Corporation Ltd
GENERAL CARE AND MAINTENANCE
By choosing an ARB Bar, you have bought a product that is one of the most sought after 4WD products in the
world. Your bar is a properly engineered, reliable, quality accessory that represents excellent value. To keep your
bar in original condition it is important to care and maintain it following these recommendations:
Prior to exposure to the weather your bar should be treated to a Carnauba based polish on all exposed
surfaces. It is recommended that this is performed on a six monthly basis or following exposure to salt, mud,
sand or other contaminants.
As part of any Pre Trip Preparation, or on an annual basis, it is recommended that a thorough visual
inspection of the bar is carried out, making sure that all bolts and other components are torqued to the correct
specification. Also check that all wiring sheaths, connectors, and fittings are free of damage. Replace any
components as necessary. This service can be performed by your local authorized ARB Stockist
Important electrical system information
The 2011-On Ford Ranger uses an advanced wiring system allowing new chassis control systems to be
used. Due to this, placing large amounts of additional load to the wiring harness may trigger faults in the
ECU or cause permanent damage to the wiring harness.
To prevent overloading the turn and clearance lights must be activated through relays. Relay looms are
provided within this kit to wire these lights. For further reference please see the attached wiring diagram at
the end of these instructions.
Maintenance of adaptive cruise control components (if fitted, available on 2015 ON Ranger) must only be
performed by an authorized ARB workshop. No adjustments to the radar and/or bull bar are permissible
following original fitment unless conducted by your local authorized ARB stockist. Regular cleaning of the
radar must be carried out in order to ensure optimal operation. Ensure that no foliage, dirt or material is
obstructing the radar‟s field of vision as this may impact the performance of the radar
REQUIRED TOOLS FOR FITMENT OF PRODUCT:
ELECTRIC DRILL & Ø2, Ø5.5,Ø7 & Ø10MM BITS
JIG SAW OR MULTI-TOOL WITH BLADE
SUITABLE FOR PLASTIC
CONVOLUTED TUBE (7MM & 12MM)
TORQUE WRENCH 9-100 Nm CAPACITY
HAVE AVAILABLE THESE SAFETY ITEMS WHEN FITTING PRODUCT:
NOTE: „WARNING‟ notes in the fitting procedure relate to OHS situations, where to avoid a
potentially hazardous situation it is suggested that protective safety gear be worn or a safe work
procedure be employed. If these notes and warnings are not heeded, injury may result.
FASTENER TORQUE SETTINGS:
