Arbiter Systems 1040C User Manual

1-4
Table 1.1 - Current Specifications
____________________________________________________________________________
TYPE DESCRIPTION
____________________________________________________________________________
I. Output, DC Current
Range 1
1
0.10 mA to 1.05 mA
Range 2 1.00 mA to 10.5 mA
Range 3 10.0 mA to 105 mA
Range 4 0.100 A to 1.05 A
Range 5 1.00 A to 10.5 A
DC Current Amplitude +(0.2% of reading +0.05% of full scale)
Accuracy
Compliance Voltage 12.0 V, <50 mA
3 V, >50 mA
Overload Setting 12.5 V, <50 mA
3.5 V, > 50 mA
Noise 0.25% rms of reading Max, 10 kHz BW
Resolution and Setability <0.1% of reading
Settling Time <8 seconds
1
Usable to 0.025 mA but not specified
