ARCCAPTAIN MIG160 - Strap Installation

28
8.
Strap Installation
1. Thread the strap through the strap hole in front of
the welder
2. Thread the strap through the nylon buckle as shown
in the diagram
3. Thread the strap through the strap hole in back of
the welder
4. Thread the strap through the nylon buckle as shown
in the diagram
Figure 41
Figure 42
Figure 43
Figure 44
