Arctic MAFP020A - Checking of State Parameters

32
Checking of State Parameters
In the main interface Press to enter the state parameter interface. Then press or button to
navigate to the state parameters.
2018 - Current
Display
Meaning
Display
Meaning
o1
Water tank temperature
A5
Main elec. Expansion valve degree
o2
Water inlet temperature
A6
Cool coil temperature
o3
Water outlet temperature
A7
DC bus voltage
o4
Ambient temperature
A8
IPM module temperature
o5
NOT USED
A9
Real-time power
o6
Auxiliary elec. Expansion valve degree
A10
Dc motor speed
A1
Discharge temperature
A11
High pressure
A2
Coil temperature
A12
Low pressure
A3
Suction temperature
A13
AC input voltage
A4
AC input current
A14
Frequency of compressor operation
2017 -2016
Display
Meaning
Display
Meaning
C0
DC inverter compressor frequency
C9
DC Voltage x 10
C1
AC Voltage x10
Ca
IPM mode temperature
C2
Compressor Discharge temperature
Cb
Real-time power x 100
C3
Compressor Suction temperature
Cc
Not Used
C4
Evaporator coil temperature
Cd
Water inlet temperature
C5
Outdoor ambient temperature
Ce
Water outlet temperature
C6
Water tank temperature
Cf
Coil Cooling Temp
C7
AC Current
CH
Not Used
C8
EEV efficiency x 10
CL
Not Used
