Operation Guide P341/EN O/B11
Installation CHAPTER 2
MiCOM P341 Page 1/10
CONTENT
1. RECEIPT OF RELAYS 3
2. HANDLING OF ELECTRONIC EQUIPMENT 3
3. STORAGE 4
4. UNPACKING 4
5. RELAY MOUNTING 4
5.1 Rack mounting 5
5.2 Panel mounting 7
6. RELAY WIRING 8
6.1 Medium and heavy duty terminal block connections 8
6.2 RS485 port 9
6.3 RTD connections (if applicable) 9
6.4 IRIG-B connections (if applicable) 9
6.5 RS232 port 10
6.6 Download/monitor port 10
6.7 Earth connection 10
Figure 1: Location of battery isolation strip 5
Figure 2: Rack mounting of relays 6
