4.2.8 Current inputs
Displayed Current Primary/Secondary*
Phase CT Ratio
è
ç
ç
æ
ø
÷
÷
ö
[Phase CT Primary]
[Phase CT Sec'y]
_______A/na*
Earth Fault CT Ratio
è
ç
ç
æ
ø
÷
÷
ö
[E/F CT Primary]
[E/F CT Sec'y]
_______A/na*
SEF CT Ratio
è
ç
ç
æ
ø
÷
÷
ö
[SEF CT Primary]
[SEF CT Sec'y]
_______A/na*
Ιnput CT
Applied value Displayed value
ΙA
_______A _______A
ΙB
_______A _______A
ΙC
_______A _______A
ΙN
_______A/na* _______A/na*
ΙN Sensitive/ISEF
_______A _______A
ΙA (2)
_______A/na* _______A/na*
ΙB (2)
_______A/na* _______A/na*
ΙC (2)
_______A/na* _______A/na*
4.2.9 Voltage inputs
Displayed Voltage Primary/Secondary*
Main VT Ratio
è
ç
ç
æ
ø
÷
÷
ö
[Main VT Primary]
[Main VT Sec'y]
_______V/na*
NVD VT Ratio
è
ç
ç
æ
ø
÷
÷
ö
[NVD VT Primary]
[NVD VT Secondary]
_______V/na*
Input VT Applied value Displayed value
Va _______V _______V
Vb _______V _______V
Vc _______V _______V
Vo _______V _______V
