23
KRYPTON PRO 302A 8. Stem Assembly
Stem Assembly - Step #2
1. Prepare the fork by routing the front brake
hose thru the inside of the left blade, out of the
left-side hole in the steerer (use the right-side
hole if you are assembling the front brake on
the right-side lever).
2. Bolt on the front brake caliper to the fork.
3. Complete the Headset installation (see p.11),
taking care to guide the brake hoses and Di2
cables into the steerer tube’s grooves.
