ARIS Tensor Zone 2/22 - ATEX Performance Data

37Tensor
10.4 Performance data
The maximum surface temperature of the actuators with regard to an ambient temperature of +45 °C is +80 °C.
Protection class
IP65
Motor • Supply: 85…265 V AC, 50/60 Hz; 24 V AC/DC
• Protection: Primary 2A Tr
• Type: BLDC
• 50/60 Hz±5%, 100% ED
• Isolation class E acc. to DIN EN 60085
Cable gland ATEX-certied cable glands acc. to required protection class, e.g.:
WISKA Hoppmann & Muslow GmbH, Type ESKE/1-e 16
EC-Type-examination certicate number: PTB 13 ATEX 1015 X
Ø cable min. 4 mm, Ø cable max. 9 mm
Path cutoff Digital via magnet sensor
Ambient temperature -15 °C bis +45 °C
Installation position Arbitrary
Potentiometer (Option) Electronic
Travel 28°…100 revolutions
Only xed installed cables and lines are allowed to be inducted.
The Operator must guarantee an appropriate strain relief.
If an error occurs: Dangerous voltage when the protective conductor is NOT connected.
Possibly electric shock!
• Connect the protective conductor terminal (s. symbol in actuator enclosure) with
the protective conductor at any time.
• Do only put the actuator in operation with connected protective conductor!
ADVICE
!
WARNING
