38 Tensor
11. Additional options
11.1 Internal manual override (mechanical)
Operating the manual override with a cordless screwdriver is not permitted because the
transmission can be destroyed due to the high speed!
Turn the drive shaft with an Allen key SW4 at the manual override until the desired position is reached.
11.2 Option hand wheel
Danger of a mechanical stroke.
The hand wheel is only allowed to be used if the system power is off!
1. Turn off operating voltage of the actuator.
2. Press down hand wheel and turn into desired direction.
Adjusted positions remain.
3. If the desired position is reached release the hand wheel (the coupled state releases).
The hand wheel does not rotate in decoupled state.
