Chapter 3: Configuration and commissioning
96 2X Series Installation Manual
Extended fire routing delay (typically for Scandinavia).
The configured fire routing delay starts to count down when the
control panel reports a detector alarm.
If the alarm is acknowledged during the configured fire routing delay
(by pressing the Panel Silence button), then the extended fire
routing delay becomes the active delay.
If the alarm is not acknowledged during the configured fire routing
delay (by pressing the Panel Silence button), then the extended fire
routing delay is not activated.
[1] Extended fire routing delay (typically for Holland).
The standard fire routing delay starts to count down when the
control panel reports a detector alarm.
If the alarm is acknowledged during the
configured fire routing delay
(by pressing the Sounders Start/Stop button), then the extended fire
routing delay becomes the active delay.
If the alarm is not acknowledged during the configured fire routing
delay (by pressing the Sounders Start/Stop button), then the
extended fire routing delay is not activated.
[1] Sounder delay must be configured as 0 seconds for this option.
Investigation time
Select the Investigation time option to configure the duration (in seconds) of the
investigation time for the configured investigation mode. Minimum, maximum,
and default values for each mode are shown in the table below.
Table 56: Investigation time values per mode
acknowledgement time 30 seconds See note [1] 60 seconds
Extended fire routing delay
)
See note [2] 600 seconds 60 seconds
Extended fire routing delay
)
See note [2] 600 seconds 60 seconds
The maximum value must be less than the minimum delay to activate a sounder or fire
The minimum value must be greater than the maximum activation delay for any fire routing
