Aritech 2X Series User Manual

Chapter 5: Technical specifications
2X Series Installation Manual 113
Configurable outputs
Supervision (Class B outputs)
Reverse polarity, end-of-line resistor 15 kΩ, 1/4 W
Supervision (Class A outputs)
Reverse polarity, end-of-line resistor 4.7 kΩ, 1/4 W
Maximu
m output current 750 mA per output at 25 ºC
600 mA per output at 40ºC (small cabinet)
675 mA per output at 40ºC (large cabinet)
Maximum electrical
characteristics for sounder
activation
1 A start-up current (t ≤ 2ms), load 100 µF
Configurable options
See Table 48 on page 85
Fire and fault outputs
Available output pairs
1 output pair for Fire
1 output pair for Fault (activated when no fault)
Output pair specifications
1 supervised output: reverse polarity, end-of-line resistor 15 kΩ,
1/4 W
1 potential free relay: C/NO/NC
Maximum output current
Supervised output
Relay output
350 mA per output for all temperature ranges
2 A / 30 VDC
24V auxiliary output
Maximum output current
500 mA at 25ºC
385 mA at 40ºC
Configurable options
Resettable, not deactivated during reset (default), inactive when
mains off, not deactivated when running on batteries (default)
Internal printer specifications
Note: The internal printer is only available on selected models.
Printing method
Thermal
Resolution
203 dpi (8 dots/mm)
Printing speed
>50 mm/s
Columns
24/40
Paper width
58 mm
Paper weight
55 to 70 g/m²
Roll dimension
Ø 30 mm max.
Character set
ASCII standard, EPSON, International
Data buffer
128 bytes
Flash memory
32 KB
Operating
temperature 0 to 50°C

Aritech 2X Series Specifications

General

Certifications	EN54-2, EN54-4
Power Supply	230V AC, 50Hz
Battery Capacity	7Ah
Current Consumption	Standby: 50mA
Humidity Range	Up to 95% RH, non-condensing
