Aritech 2X Series User Manual

Appendix A: Default configurations
118 2X Series Installation Manual
Description
Default setting
OUT1, OUT2
, etc. (Class B) Sounder output (all zones)
Fire output
Activated by fire alarms in all zones
Fault ou
tput Follows the General Fault LED and is activated when there
is no fault (fail-to-safe)
IN1 and IN2
Technical alarm latched (T_AL)
Delays
All delays to 0 in all zones
Sounder, fire routing, fire protection, and program groups to
be activated by all zones
Sounders silence disable time 60 seconds
Expansion boards
None

Aritech 2X Series Specifications

General

Certifications	EN54-2, EN54-4
Power Supply	230V AC, 50Hz
Battery Capacity	7Ah
Current Consumption	Standby: 50mA
Humidity Range	Up to 95% RH, non-condensing
