Aritech 2X Series User Manual

Chapter 1: Introduction
2X Series Installation Manual 7
Control/LED
LED colour Description
Fire Routing Delay
button and LED
Yellow Enables or disables a previously configured fire routing
delay. Cancels a delay as it counts down and activates
fire routing.
A steady LED indicates that a delay is configured and
enabled. A flashing LED indicates that a delay is
counting (fire routing is activated when the configured
delay elapses or when the delay is cancelled).
Fire Routing
Fault/Disabled
/Test
LED
Yellow Indicates a fire routing fault, disablement, or test.
A flashing LED indicates a fault. A steady LED indicates
a disablement or a test.
Fire Protection
On/Acknowledged
button and LED
Red Cancels a previously configured delay as it counts
down and activates fire protection.
A flashing LED indicates that fire protection has been
activated. A steady LED indicates that the fire
protection signal has been acknowledged by the remote
monitoring equipment.
Fire Protection Delay
button and LED
Yellow Enables or disables a previously configured fire
protection delay. Cancels a delay as it counts down and
activates fire protection.
A steady LED indicates that a delay is configured and
enabled. A flashing LED indicates that a delay is
counting (fire protection is activated when the
configured delay elapses or when the delay is
cancelled).
Fire Protection
Fault/Disabled/Test
LED
Yellow Indicates a fire protection fault, disablement, or test.
A flashing LED indicates a fault. A steady LED indicates
a disablement or a test.
Sounder Delay button
and
LED
Yellow Enables or disables a previously configured sounder
delay. Cancels a delay as it counts down and activates
sounders.
A steady LED indicates that a sounder delay is
configured and enabled. A flashing LED indicates a
delay is counting (sounders are activated when the
configured delay elapses or when the delay is
cancelled).
Sounder
Fault/Disabled
/Test
LED
Yellow Indicates a sounder fault, disablement, or test.
A flashing LED indicates a fault.
A steady LED indicates
a disablement or a test.
Supp
ly Fault LED Yellow Indicates a power supply fault.
A flashing LED indicates a battery fault. A steady LED
indicates a mains or mains fuse fault.
Earth Fault LED
Yellow Indicates an earth isolation fault.
Low Battery LED
Yellow Indicates that the control panel is running on battery
power and that the remaining charge may be
insufficient to guarantee continued operation.
System Fault LED
Yellow Indicates a control panel system failure.

Aritech 2X Series Specifications

General

Certifications	EN54-2, EN54-4
Power Supply	230V AC, 50Hz
Battery Capacity	7Ah
Current Consumption	Standby: 50mA
Humidity Range	Up to 95% RH, non-condensing
