Chapter 1: Introduction
2X Series Installation Manual 13
Loop device not configured
A loop device is detected that is not configured
Maximum conventional zones
exceeded in a network
The number of conventional zones in a fire network
exceeds the maximum allowed (64)
Maximum loops exceeded in a
network
The number of loops in a fire network exceeds the
maximum allowed (32)
New node in the fire network
A control panel has been added to the fire network
An output group is activated
A device (and corresponding zone) is in prealarm
Sounder, fire routing, and fire
protection delays
A sounder, fire routing, or fire protection delay is enabled or
disabled
A control panel feature or device is being tested
[1] These condition types only apply if an extinguishing panel is included in the fire network.
In addition to the above, the following system status events are also added to the
event log (but are not included in the control panel current events report).
Table 8: Other system status events added to the event log
An output group is activated or deactivated or a
programmable system command is executed (via the
Configuration Utility)
A system condition is deactivated
The control panel is reset, the panel is silenced, a new date
and time is set, the system is initiated, etc.
Power supply faults eliminated
A previously logged power supply fault is resolved
ion A rule is activated [1]
The date and time information for activation and termination
of user sessions
A rule consists of one or more states (combined by Boolean operators) that are configured to
trigger specific system actions after
a specific confirmation time. Rules are created using the
