Arjo Auralis - Page 31

Figure 43
Figure 44
ASSEMBLE THE AURALIS SYSTEM
31
NOTE
If the chair is of the closed side type with a
non-removable seat cushion, then security
relies only on the non-slip base material of
the seat cushion.
• Closed chair with non-removable seat
cushion
Position the Auralis cushion on the chair.
3.
CAUTION
To avoid damage to the cells, always
use the Auralis seat cushion with the
protective top cover.
Place the protective cover over the Auralis seat
cushion. Make sure the Arjo logo is visible at the
front part of the seat.
4. Zip the cover onto the Auralis seat cushion. Do not
trap any material in the zip. Make sure the zip is
fully closed.
5.
Place the Auralis pump
RQWKHÀRRUQH[WWRWKH
chair
. Make sure:
• the cable is under the chair.
• the tube-set is placed along the side of the
chair.
See Figure 43
6. Check that the tube-set is not twisted.
7. Connect the tube-set to the Auralis pump. Make
sure the tube-set clicks into place. See Figure 44
WARNING
To avoid falling, position the Auralis
pump, the cable and the tube-set so that
they do not create a trip hazard.
