Other Specifications
Temperature sensors T1 – T4 Type k, 0 – 200
o
C
Pressure sensor L1 Piezo, 0 - 300mm H2O (gauge)
Pressure sensors P1 – P3 Piezo, 0 - 355.6mm (differential)
Turbine flowmeter 0.2 – 1.5 litres/min
Solenoid valve SOL1 Orifice 2.4mm diameter
Solenoid valve SOL2 Orifice 2.4mm diameter
Solenoid valve SOL3 Orifice 3.2mm diameter
Proportioning Solenoid Valve Orifice 2.4mm diameter
Peristaltic Pump Flow rate (6.3mm ID tube) 0 – 1.3 litres/min (nominal)
Large Process Vessel Capacity (Full) 6.8 litres (nominal)
Large Process Vessel Capacity (Reduced) 4 litres (nominal)
Heater power (small process vessel) 2 kW (nominal)
Maximum hot water temperature 80
o
C (nominal)
Environmental Conditions
This equipment has been designed for operation in the following environmental
conditions. Operation outside of these conditions may result reduced performance,
damage to the equipment or hazard to the operator.
a. Indoor use;
b. Altitude up to 2000m;
c. Temperature 5°C to 40°C;
d. Maximum relative humidity 80% for temperatures up to 31°C, decreasing
linearly to 50% relative humidity at 40°C;
e. Mains supply voltage fluctuations up to ±10% of the nominal voltage;
f. Transient over-voltages typically present on the MAINS supply;
Note: The normal level of transient over-voltages is impulse withstand (over-
voltage) category II of IEC 60364-4-443;
