Equipment Specifications
Overall Dimensions
Height - 0.725m
Width - 1.000m (plinth)
Depth - 0.530m (plinth plus pumps)
USB Channel Numbers
The channel numbers for the USB port are listed below for information:
Pin
No
Channel No PCT43 Function Signal Eng Unit
1 Channel 0 Temperature T1 0 – 5V 0 –200
o
C
2 Channel 1 Temperature T2 0 – 5V 0 –200
o
C
3 Channel 2 Temperature T3 0 – 5V 0 –200
o
C
4 Channel 3 Temperature T4 0 – 5V 0 –200
o
C
5 Channel 4 Pressure P1 0 – 5V 0 – 355.6mm
6 Channel 5 Pressure P2 0 – 5V 0 – 355.6mm
7 Channel 6 Pressure P3 0 – 5V 0 – 355.6mm
8 Channel 7 Level L1 0 – 5V 0 – 300mm
9 Channel 8 Flowrate F1 0 – 5V 0 – 1.5 l/min
10 Channel 9 USER INPUT 0 – 5V -
11 Channel 10 Conductivity 0 – 5V 0 – 200 mS
12 Channel 11 pH 0 – 5V 0 – 14 pH
13 Channel 12 Not used
14 Channel 13 Not used
15 Channel 14 Not used
16 +5V Out +5V Supply
17 Analog ground 0V
