ARRI SkyPanel X - Product Layout - Left View; ALL-WEATHER Control Panel Layout

Product Overview | 4
SkyPanel X Operating Manual 21
Left View
13 13
14
15
15
17
18
19
16
Illustration2: Left View (as seen from the front)
13 Rubber foot (3x)
14 Drain for control panel recess
15 Accessories holder (4x)
16 Retaining clip for accessories (left and right
side)
17 Yoke bracket (left and right side)
18 Quick release lever
19 Handle and safety rope attachment
4.2 Accessory Layout
ALL-WEATHER Control Panel
51 2 3 4
Illustration3: ALL-WEATHER Control Panel Layout
1 Connectors to SkyPanel X
2 4 pin Lemo connector
3 Neodym magnet
4 Thread for D ring
5 Sensor for display brightness
