2 | About this Product
8 SkyPanel X Operating Manual
2.5 Technical Data (Single Device)
Physical
Wide x height x depth (without yoke) 738 x 339 x 154 mm / 29.1 x 13.3 x 6.1 in
Weight (without yoke and accessories) 15 kg / 33 lbs
Construction
Color blue / silver
Housing Composite and aluminum
Protection glass 3 mm, IK06
Protection rating IP 66
Protection Class I
Installation
Mounting 28 mm Spigot
Approved inclination +/- 90°
Minimum clearance around device 20in/0.5m
Minimum distance from light aperture to persons,
objects or surfaces
1.0 m / 40in
Thermal
Cooling passive and active cooling
Number of fans 2
Noise level (High CRI Vari Fan) <= 30 dB(A)
Noise level (Standard) <= 20 dB(A)
Noise level (High Output) <= 38 dB(A)
Electrical
Power supply range 100 - 240 V ~, 50 / 60 Hz
Battery power range 48 V - 52 V =
Typical power draw 800 W
Control and Programming
DMX channels 12 - 156, depending on mode
Setting and addressing User menu and remote via control network, web
portal, Bluetooth 5.0
DMX compliance ESTA DMX512A
LumenRadio CRMX, CRMX-2, W-DMX (all
generations)
RDM compliance ANSI E1.31
Art-Net Version 4
sACN ANSI E1.31
HTTP Web, mDNS Bonjour, PTP, NTP
Firmware update Via USB port, network and ALSM
