About this Product | 2
SkyPanel X Operating Manual 9
Connectors
MAINS IN/THRU powerCON TRUE1 TOP
BATTERY 48V DC 3-pin XLR connector, male
DMX IN / DMX OUT 5-pin XLR
LAN 1/2 RJ-45 connector (EtherCON compatible), IP 65
Control Panel PoE socket, LEMO, IP 69
Light Source
Type Full Spectrum, 6-color RGBACL LED
Number of light engines 4
Calibrated white light range 1.500 K - 20.000 K
Colored light RGBACL color mixing
Color rendition index CRI 90 min. / 99 max. (High CRI VariFan mode)
TLCI 93 (typical, High CRI VariFan mode)
Green – Magenta point -1 / +1
Optical Path
Type Soft or hard light
Open face, beam angle 120°
X21 Dome, beam angle 106°
HyPer optic, beam angle 11°
Dynamic Functions
Dimmer electronic, 0 - 100%
Color mixing CCT, HSI, RGBW, RGBACL, Effect, XY, Gel,
Source Matching
User Interface
Device menu Detachable ALL-WEATHER control panel with
display and buttons
USB-C port USB 2.0
5 V / 3.0 A
Note: Technical data is subject to change without notice.
